Basic Specifications PC USB Oscilloscope Hantek 6022BE

Channel
2 Chanel
Bandwidth
20Mhz
Input Impedance
1MΩ 25pF
Max. Sample rate
48MS/s
Coupling
DC
Vertical resolution
8Bit
Gain range
10mV-5V, 9Steps
DC accuracy
±3%
Timebase range
4ns-5ks
Vertical adjustable
Yes
Input protection
Diode clamping
X-Y
Yes
EXT. input
No
Trigger Mode
Auto, Normal and Single
Trigger Slope
+/-
Trigger level adjustable
Yes
Trigger Type
Rising edge, falling edge
Trigger Source
CH1, CH2
Pre/Post trigger
0-100%
Buffer size
1M
Sampling selection
Yes
Waveform Display
port/line, waveform average, persistence, intensity
Network
Open/Close
Vertical mode
CH1, CH2, Dual, ADD
Cursor measurement
Yes
Math
FFT, addition, subtraction, multiplication, division.
Cursor
Frequency, Voltage
Accessories
S/W CD, probes, manual, USB cord
